Description
Function / Homologation
| Functions | High Beam Low Beam Direction Indicator Daytime Running Light Position |
|---|---|
| Homologation | ECE R112, R7, R6, R10 |
Optical & Electrical Features
| LED Info | High Beam: 9pcs 3W LEDs Low Beam: 1pcs 15W LEDs Direction Indicator: 6pcs 3W LEDs Position / DRL: 12pcs 2W LEDs (Dual Intensity) |
| Emitting Colour | White Amber (DI) |
| Energy Consumption | High Beam: 31W Low Beam: 14.5W Direction Indicator : 15.2W Daytime Running Light: 7.7W Position: 1.1W |
| Current Draw @ 12 VDC | High Beam : 2.58A Low Beam : 1.21A Direction Indicator :1.27A Daytime Running Light : 0.64A Position : 0.092A |
Mechanical Features
| Housing Material | Aluminium |
| Lens Material | Anti – UV polycarbonate |
| Mounting Arrangement | 4 Adjusters |
| IP Rating | IP66 |
